Technical Specifications
- Max Input Power: 75KW
- MPPT voltage range / rated input voltage: 200V to 850V / 620V
- No. of MPPT / No. of DC Inputs per MPPT: 4 / 2
- Max. PV input current: 30Ax4
- Battery voltage range: 200V to 850V*
- Rated grid side output power: 50kW
- Max. grid side output apparent power: 55kVA
- Max. grid side input apparent power: 60kVA
- Rated back-up side output power: 50kW
- Max. switch time: <20ms
- Ingree protection degree: IP65
Multiple Protection Measures
The system incorporates multiple protection functions including DC reverse polarity protection, surge protection, insulation resistance protection, AC over-voltage protection, overload protection, and AC short-circuit protection, ensuring comprehensive safety during system operation.
Type 2 Surge Protection
Both AC and DC sides are equipped with MOV secondary lightning protection, reducing the risk of equipment failure caused by unstable factors such as lightning strikes, ensuring the stable operation of the power system.
UPS-Level Grid-tied and Off-grid Switching
The <20ms grid-tied and off-grid switching feature protects equipment by ensuring continuous power supply, thereby guaranteeing the stable operation of the electrical system.
DOWNLOAD DATA SHEET: CESS-HY-25K -50K
